1″ B&C DE12TC
Key Features
60 W continuous program power capacity
1″ horn throat diameter
36 mm (1.4 in) aluminium voice coil
Titanium diaphragm
1500 – 18000 Hz response
105 dB sensitivity -
1″ B&C DH350H 4Ω|8Ω|16Ω
HLX Series – The Helical Approach
B&C has a reputation for performance, by turning the limits of traditional compression driver design on their head. HLX™: Compression driver efficiency in miniature. The HLX™ phase plug…
-
1″ B&C DE550TN 8Ω|16Ω
Key Features
140 W continuous program power capacity
1″ horn throat diameter
51 mm (2 in) aluminium voice coil
Titanium diaphragm
1000 – 17000 Hz response
108 dB sensitivity -
Beyma DRIVER CD10ND/N 8 OH
● 1” (25,4 mm) high frequency compression driver ● High sensitivity: 111 dB (1W / 1m) ● Ultra lightweight edgewound aluminium ribbon voice coil ● Aluminium cover ● Neodymium magnet
-
1″ B&C DE180
Key Features
120 W continuous program power capacity
1′ horn throat diameter
44 mm (1.7 in) aluminium voice coil
Polyimide diaphragm
1000 – 17000 Hz response
106.5 dB sensitivity -
1″ B&C DE14 8Ω|16Ω
Key Features
60 W continuous program power capacity
1″ horn throat diameter
36 mm (1.4 in) CCAW voice coil
Polyester diaphragm
1500 – 18000 Hz response
105 dB sensitivity -
1″ B&C DH450 8Ω|16Ω
HLX Series – The Helical Approach
B&C has a reputation for performance, by turning the limits of traditional compression driver design on their head. HLX™ : Compression driver efficiency in miniature. The HLX™ phase plug…
-
Beyma DRIVER CD-101Nd/PT 8 OH
Key Features
● Next generation high performance 1” (25,4 mm) exit compression driver
● Deplocex® Patent Pending Technology for improved thermal disipation, low power compression losses and high power handling
● 1,1” (28… -
0.75″ B&C DE7 4Ω|8Ω|16Ω
Available exclusively with 4.8+2.8 mm fast-on terminal tab
Key Features20 W continuous program power capacity
25 mm (1 in) aluminium voice coil
3/4″ horn throat diameter
Polyester diaphragm
2000 -… -
0.75″ B&C WG7
Wave guide horn not sold separately
Available exclusively with 4.8+2.8 mm fast-on terminal tab
Key FeaturesLine Array optimized Waveguide with two DE7 drivers
150° max horizontal coverage
40 W continuous program… -
Beyma DRIVER CD10FE/N 8 OH
● 1” (25,4 mm) high frequency compression driver ● Sensitivity 109 dB (1W / 1m) ● Ultra lightweight edgewound aluminium ribbon voice coil ● Aluminium cover
-
1″ B&C DH350 4Ω|8Ω|16Ω
HLX Series – The Helical Approach
B&C has a reputation for performance, by turning the limits of traditional compression driver design on their head. HLX™ : Compression driver efficiency in miniature. The HLX™ phase plug…
