B&C CROSSOVER FB354V2 8Ω|16Ω
Reinforced PRO version of the popular FB354 crossover, for more challenging applications. The FB354v2 shares the same circuit diagram of the FB354, substituting inductors with higher power ratings and eliminating the built-in light bulb protection network. The FB354v2 allows the user more control to optimize DSP limiter settings for higher maximum SPL while maintaining a safe work margin for the DCX354.
Teirautis telefonu
+37069873838
darius@combo.lt
- Aprašymas
- Atsiliepimai (0)
Aprašymas
General
Nominal Impedance: 8 Ω
Specifications
Crossover Frequency: 5.6 kHz
Slope: 18 – 12 dB/oct
Filter Type: Two Way
Overall Dimensions: 105×137 mm (4.13×5.39 in)
Mounting and Shipping Info
Other details: 4 mm diameter holes on the PCB at 127 mm x 95 mm
Shipping Units: 1 pcs
Shipping Box: 147x117x58 mm (5.79×4.61×2.28 in)
Net Weight: 0.55 kg (1.21 lb)
Shipping Weight: 0.59 kg (1.3 lb)
