1″ B&C DE400TN 8Ω|16Ω
Key Features
100 W continuous program power capacity
1′ horn throat diameter
44 mm (1.7 in) aluminium voice coil
Titanium diaphragm
1200 – 18000 Hz response
106 dB sensitivity
Compact… -
15″ B&C HCX76
Key Features
99 dB sensitivity
Single Neodymium magnet assembly
800 W continuous program power capacity
60°x40° nominal coverage
40 – 18000 Hz response
Modified exponential horn flare for improved acoustic… -
1″ B&C DE10
Key Features
40 W continuous program power capacity
1″ horn throat diameter
25 mm (1 in) aluminium voice coil
Polyester diaphragm
1500 – 18000 Hz response
107 dB sensitivity -
12″ B&C HCX76
Key Features
700 W continuous program power capacity
60°x40° nominal coverage
45 – 18000 Hz response
99 dB sensitivity
Single Neodymium magnet assembly
Modified exponential horn flare for improved acoustic… -
2″ B&C ME60
Key Features
2″ throat entry
60° x 40° nominal coverage
Constant Directivity
Very good loading down to 800 Hz -
1.4″ B&C WGX980TN
Wave guide horn not sold separately
Key FeaturesLine Array optimized Waveguide with DE980TN driver
120° max horizontal coverage
220 W continuous program power capacity
75 mm (3 in) CCAW voice… -
1.4″ B&C DE52
Key Features
140 W continuous program power capacity
1.4″ horn throat diameter
51 mm (2 in) aluminium voice coil
HT Polymer diaphragm
1000 – 17000 Hz response
108 dB sensitivity -
1.4″ B&C WG148-780TN
Key Features
Line Array optimized Waveguide with DE780TN8 driver
120° max horizontal coverage
107.6 dB sensitivity
220 W continuous program power capacity
Neodymium magnet assembly with shorting copper cap -
1.4″ B&C DCM414 8Ω|16Ω
B&C engineers have been working for the last five years on a family of next generation high frequency devices. Compression drivers are the linchpin of a PA system: operating at…
-
1.3″ B&C DE910
Key Features
160 W continuous program power capacity
1.3″ horn throat diameter
75 mm (3 in) aluminium voice coil
Composite Polyester/Titanium diaphragm
500-18000 Hz response
109.5 dB sensitivity
Neodymium magnet… -
14.” B&C WGX800
Wave guide horn not sold separately
Key FeaturesLine Array optimized Waveguide with DE800 driver
120° max horizontal coverage
220 W continuous program power capacity
75 mm (3 in) aluminium voice… -
15″ B&C Subwoofer SW100 4Ω|8Ω
Key Features
3000 W continuous program power capacity
100 mm (4 in) split winding copper voice coil
40 – 1500 Hz response
95 dB sensitivity
57 mm peak-to-peak excursion before…
