6″ B&C Midrange MDN44 8Ω|16Ω
Key Features
- 400 W continuous program power capacity
- 44 mm (1.7 in) aluminium voice coil
- 150 – 6000 Hz response
- 96.5 dB sensitivity
- Neodymium magnet allows a very light yet powerful motor assembly
- Aluminium demodulating ring for very low distortion
- Ventilated voice coil gap for reduced power compression
Teirautis telefonu
+37069873838
darius@combo.lt
- Aprašymas
- Atsiliepimai (0)
Aprašymas
8 Ω | 16 Ω
Specifications
Nominal Diameter: 170 mm (6.5 in)
Minimum Impedance: 6.5 Ω
Continuous Power Handling: 400 W
Frequency Range: 150 Hz – 6000 Hz
Winding Material: Aluminium
Winding Depth: 10 mm (0.37 in)
Flux Density: 1.45 T
Nominal Impedance: 8 Ω
Nominal Power Handling: 200 W
Sensitivity: 96.5 dB
Voice Coil Diameter: 44 mm (1.7 in)
Former Material: Glass Fibre
Magnetic Gap Depth: 6 mm (0.25 in)
Woofer Cone Treatment: WP Waterproof Front Side
Parameters
Fs: 140 Hz
Qes: 0.46
Qts: 0.4
Sd: 132 cm² (20.5 in²)
Xmax: 2.5 mm
Mms: 11 g
Le: 0.47 mH
Re: 5.4 Ω
Qms: 2.8
Vas: 2.7 dm³ (0.09 ft³)
η₀: 1.6%
Xvar: 3 mm
Bl: 11 Tm
EBP: 304 Hz
Design
Surround Shape: Triple Roll
Magnet Material: Neodymium Ring
Pole Design: T-Pole
Cone Shape: Exponential
Spider: Single
Woofer Cone Treatment: WP Waterproof Front Side
Mounting and Shipping Info
Overall Diameter: 187 mm (7.4 in)
Baffle Cutout Diameter: 145 mm (5.7 in)
Flange and Gasket Thickness: 11 mm (0.4 in)
Net Weight: 1 kg (1.2 lb)
Shipping Weight: 1.2 kg (2.65 lb)
Bolt Circle Diameter: 172 mm (6.7 in)
Depth: 73 mm (2.9 in)
Air Volume Occupied by Driver: 0.6 dm³ (0.02 ft³)
Shipping Units: 1 pcs
Shipping Box: 210x210x125 mm (8.27×8.27×4.92 in)
Service Kit
Recone Kit: RCK06MDN448
Cone
Gasket
Dust Cap
Wooterprof Treatment
Centering Shims
