2″ B&C DE64TN

Specifications

Throat Diameter: 50 mm (2 in)
Nominal Impedance: 8 Ω
Minimum Impedance: 8.4 Ω
Nominal Power Handling: 110 W
Continuous Power Handling: 220 W
Sensitivity: 107.5 dB
Frequency Range: 1 kHz – 18 kHz
Recommended Crossover: 1 kHz
Voice Coil Diameter: 75 mm (3 in)
Winding Material: Aluminium
Inductance: 0.14 mH
Flux Density: 1.6 T
Diaphragm Material: Titanium
Min Frequency Range: 1 Hz
Max Frequency Range: 18 Hz

Mounting and Shipping Info

Mounting: Four M6 holes 90° on 102 mm (4 in) diameter
Overall Diameter: 156 mm (6.1 in)
Depth: 66 mm (2.6 in)
Net Weight: 3.9 kg (8.6 lb)
Shipping Units: 1 pcs
Shipping Weight: 4.02 kg (8.86 lb)
Shipping Box: 190x190x80 mm (7.48×7.48×3.15 in)

Service Kit

hf Replacement Diaphragm: MMD3BTN8M

Specification PDF
