2″ B&C DE1095TN
The DE1095TN is one of the latest versions of our premium 100mm (4.0 in) voice coil, neodymium high frequency driver. The diaphragm in this model has been completely redesigned to incorporate a bent edge voice coil former as well as new dome and surround geometry. These modifications combine to better control diaphragm displacement and deformations, resulting in lower distortion and a smoother higher frequency response above 10kHz.
Key Features
- 2″ horn throat diameter
- 240 W continuous program power capacity
- 100 mm (4 in) aluminium voice coil
- Titanium diaphragm
- 500 – 20000 Hz response
- 108 dB sensitivity
- Neodymium magnet assembly with shorting copper cap
Teirautis telefonu
+37069873838
darius@combo.lt
- Aprašymas
- Atsiliepimai (0)
Aprašymas
Specifications
Throat Diameter: 50 mm (2 in)
Nominal Impedance: 8 Ω
Minimum Impedance: 8.3 Ω
Nominal Power Handling: 120 W
Continuous Power Handling: 240 W
Sensitivity: 108 dB
Frequency Range: 0.5 kHz – 20 kHz
Recommended Crossover: 0.8 kHz
Voice Coil Diameter: 100 mm (4 in)
Winding Material: Aluminium
Inductance: 0.18 mH
Flux Density: 1.9 T
Diaphragm Material: Titanium
Min Frequency Range: 0.5 Hz
Max Frequency Range: 20 Hz
Mounting and Shipping Info
Mounting: Four M6 holes 90° on 102 mm (4 in) diameter
Overall Diameter: 127 mm (5 in)
Depth: 89 mm (3.5 in)
Net Weight: 2.14 kg (4.71 lb)
Shipping Units: 1 pcs
Shipping Weight: 2.4 kg (5.28 lb)
Shipping Box: 190x190x120 mm (7.48×7.48×4.72 in)
Service Kit
hf Replacement Diaphragm: MMD4CTN8M
