15″ B&C FHX76
Key Features
- 98 dB sensitivity
- 800 W continuous program power capacity
- 60°x40° nominal coverage
- 40 – 18000 Hz response
- Modified exponential horn flare for improved acoustic loading and controlled coverage
- 33 mm (1.3”) HF unit exit diameter
- Single Ferrite magnet assembly
Teirautis telefonu
+37069873838
darius@combo.lt
- Aprašymas
- Atsiliepimai (0)
Aprašymas
General
Nominal Diameter: 380 mm (15 in)
Frequency Range: 40 Hz – 18000 Hz
Nominal Impedance: 8 Ω
Dispersion Angle: 60 °
Specifications LF Unit
Nominal Diameter: 380 mm (15 in)
Nominal Impedance: 8 Ω
Minimum Impedance: 6 Ω
Nominal Power Handling: 400 W
Continuous Power Handling: 800 W
Sensitivity: 98 dB
Voice Coil Diameter: 76 mm (3 in)
Winding Material: Copper
Former Material: Glass Fibre
Winding Depth: 16.5 mm (0.65 in)
Magnetic Gap Depth: 8 mm (0.31 in)
Flux Density: 1.15 T
Woofer Cone Treatment: WP Waterproof Front Side
Specifications HF Unit
Nominal Diameter: 380 mm (15 in)
Nominal Impedance: 8 Ω
Minimum Impedance: 7.5 Ω
Nominal Power Handling: 80 W
Continuous Power Handling: 160 W
Sensitivity: 107 dB
Recommended Crossover: 1.2 kHz
Voice Coil Diameter: 75 mm (3 in)
Winding Material: Aluminium
Inductance: 0.14 mH
Flux Density: 1.6 T
Diaphragm Material: Titanium
Design
Magnet Material: Ferrite
Woofer Cone Treatment: WP Waterproof Front Side
Parameters
Fs: 40 Hz
Re: 5.2 Ω
Qes: 0.47
Qms: 5.2
Qts: 0.43
Vas: 186 dm³ (6.56 ft³)
Sd: 855 cm² (132.5 in²)
η₀: 2.4 %
Xvar: 7 mm
Mms: 88 g
Bl: 15.5 Tm
Le: 1.5 mH
EBP: 85 Hz
Mounting and Shipping Info
Overall Diameter: 393 mm (15.5 in)
Baffle Cutout Diameter: 354 mm (13.94 in)
Bolt Circle Diameter: 374 mm (14.7 in)
Flange and Gasket Thickness: 16 mm (0.62 in)
Depth: 199 mm (7.83 in)
Net Weight: 9.2 kg (20.28 lb)
Shipping Units: 1 pcs
Shipping Weight: 10.8 kg (23.81 lb)
Shipping Box: 500x495x275 mm (19.69×19.49×10.83 in)
Service Kit
HF Replacement Diaphragm: MMD3BTN8M
LF Recone Kit: RCK15FHX768
Cone
Gasket
Centering Shims
