10″ B&C Woofer PS26

Specifications

Nominal Diameter: 250 mm (10 in)
Minimum Impedance: 7.1 Ω
Continuous Power Handling: 700 W
Frequency Range: 55 Hz – 4000 Hz
Winding Material: Aluminium
Winding Depth: 18 mm (0.71 in)
Flux Density: 0.9 T
Nominal Impedance: 8 Ω
Nominal Power Handling: 350 W
Sensitivity: 96 dB
Voice Coil Diameter: 76 mm (3 in)
Former Material: Glass Fibre
Magnetic Gap Depth: 10 mm (0.4 in)
Woofer Cone Treatment: None

Parameters

Fs: 54 Hz
Qes: 0.33
Qts: 0.29
Sd: 320 cm² (49.1 in²)
Xmax: 5.5 mm
Mms: 33 g
Le: 1.2 mH
Re: 6 Ω
Qms: 2.9
Vas: 38 dm³ (1.3 ft³)
η₀: 1.8 %
Xvar: 5 mm
Bl: 14.1 Tm
EBP: 164 Hz

Design

Surround Shape: Double Roll
Magnet Material: Ferrite
Pole Design: T-Pole
Recommended Enclosure: 25 dm³ (0.88 ft³)
Cone Shape: Exponential
Spider: Single
Woofer Cone Treatment: None
Recommended Tuning: 65 Hz

Mounting and Shipping Info

Overall Diameter: 262 mm (10.3 in)
Baffle Cutout Diameter: 230 mm (8.8 in)
Flange and Gasket Thickness: 14 mm (0.55 in)
Net Weight: 6.05 kg (13.34 lb)
Shipping Weight: 6.65 kg (14.66 lb)
Bolt Circle Diameter: 245 mm (9.6 in)
Depth: 123 mm (4.8 in)
Shipping Units: 1 pcs
Shipping Box: 295x314x175 mm (11.61×12.36×6.89 in)

Service Kit

Recone Kit: RCK010PS268
Cone
Gasket
Centering Shims

Specification PDF
