10″ B&C Woofer CL64

Specifications

Nominal Diameter: 250 mm (10 in)
Minimum Impedance: 6.3 Ω
Continuous Power Handling: 500 W
Frequency Range: 65 Hz – 4000 Hz
Winding Material: Copper
Winding Depth: 14.3 mm (0.56 in)
Flux Density: 1.16 T
Nominal Impedance: 8 Ω
Nominal Power Handling: 250 W
Sensitivity: 96 dB
Voice Coil Diameter: 64 mm (2.5 in)
Former Material: Glass Fibre
Magnetic Gap Depth: 8 mm (0.31 in)
Woofer Cone Treatment: WP Waterproof Front Side

Parameters

Fs: 63 Hz
Qes: 0.33
Qts: 0.31
Sd: 320 cm² (49.6 in²)
Xmax: 5.2 mm
Mms: 41.6 g
Le: 1.17 mH
Re: 5.3 Ω
Qms: 5.1
Vas: 22.2 dm³ (0.78 ft³)
η₀: 1.69%
Xvar: 6 mm
Bl: 16.3 Tm
EBP: 191 Hz

Design

Surround Shape: Double Roll
Magnet Material: Neodymium Inside Slug
Pole Design: T-Pole
Recommended Enclosure: 29 dm³ (1.02 ft³)
Cone Shape: Exponential
Spider: Single
Woofer Cone Treatment: WP Waterproof Front Side
Recommended Tuning: 65 Hz

Mounting and Shipping Info

Overall Diameter: 258 mm (10.16 in)
Baffle Cutout Diameter: 232 mm (9.13 in)
Flange and Gasket Thickness: 10 mm (0.39 in)
Net Weight: 2 kg (4.41 lb)
Shipping Weight: 2.6 kg (5.73 lb)
Bolt Circle Diameter: 245 mm (9.65 in)
Depth: 112 mm (4.41 in)
Air Volume Occupied by Driver: 1 dm³ (0.04 ft³)
Shipping Units: 1 pcs
Shipping Box: 295x314x175 mm (11.61×12.36×6.89 in)

Service Kit

Recone Kit: RCK10CL648
Cone
Gasket
Dust Cap
Wooterprof Treatment
Centering Shims
