10″ B&C Midrange NSM76 8Ω|16Ω
For simplified cabinet assembly and efficient thermal transfer to the air, our NSM series of sealed back midranges feature a cast aluminum sealed chassis, high strength neodymium motor, and large internal volume for good low frequency performance. Large voice coils provide power handling, while careful selection of suspension and cone components results in exceptional sensitivity. These dedicated narrow-bandwidth midranges offer the lowest distortion at given output of any midrange available.
Available exclusively with 6.3+4.8 mm fast-on terminal tab
Key Features
- 800 W continuous program power capacity
- 76 mm (3 in) aluminium voice coil
- 235 – 3500 Hz response
- 99 dB sensitivity
- Ideal for Direct Radiation and Horn Loaded Midrange application
Teirautis telefonu
+37069873838
darius@combo.lt
- Aprašymas
- Atsiliepimai (0)
Aprašymas
Specifications
Nominal Diameter: 250 mm (10 in)
Minimum Impedance: 14 Ω
Continuous Power Handling: 800 W
Frequency Range: 235 Hz – 3500 Hz
Winding Material: Aluminium
Winding Depth: 11.5 mm (0.45 in)
Flux Density: 1.6 T
Nominal Impedance: 16 Ω
Nominal Power Handling: 400 W
Sensitivity: 99 dB
Voice Coil Diameter: 76 mm (3 in)
Former Material: Glass Fibre
Magnetic Gap Depth: 9 mm (0.35 in)
Woofer Cone Treatment: WP Waterproof Front Side
Parameters
Fs: 235 Hz
Qes: 0.72
Qts: 0.66
Sd: 320 cm² (49.6 in²)
Xmax: 3.5 mm
Mms: 33 g
Le: 1.5 mH
Re: 10.7 Ω
Qms: 8.7
Vas: 2 dm³ (0.07 ft³)
η₀: 3.5%
Xvar: 3.5 mm
Bl: 21.5 Tm
EBP: 326 Hz
Design
Surround Shape: Accordion
Magnet Material: Neodymium Ring
Pole Design: T-Pole
Cone Shape: Radial
Spider: Single
Woofer Cone Treatment: WP Waterproof Front Side
Mounting and Shipping Info
Overall Diameter: 291 mm (11.46 in)
Baffle Cutout Diameter: 234 mm (9.21 in)
Flange and Gasket Thickness: 12 mm (0.47 in)
Net Weight: 4.55 kg (10.03 lb)
Shipping Weight: 5.45 kg (12.02 lb)
Bolt Circle Diameter: 274 mm (10.79 in)
Depth: 130 mm (5.12 in)
Air Volume Occupied by Driver: 5 dm³ (0.18 ft³)
Shipping Units: 1 pcs
Shipping Box: 360x360x200 mm (14.17×14.17×7.87 in)
Service Kit
Recone Kit: RCK010NSM7616
Cone
Gasket
Centering Shims
