10″ B&C Midbass MBX64 8Ω|16Ω
The MBX series mid-bass woofers from B&C Speakers offer acoustic designers a new range of high efficiency, wide bandwidth alternatives that are not currently available in the B&C range. These full-featured transducers incorporate lightweight neodymium motors, inside/outside wound copper clad aluminum wire voice coils, weatherproof impregnated paper cones, and a symmetrical inductance profile. The MBX Series is especially well suited for two-way loudspeaker enclosures.
Key Features
- 700 W continuous program power capacity
- 64 mm (2.5 in) aluminium voice coil
- 65 – 6000 Hz response
- 100 dB sensitivity
- Neodymium inside slug magnet assembly
- Aluminium demodulating ring allows a very low distortion figure
- Ventilated voice coil gap for reduced power compression
Teirautis telefonu
+37069873838
darius@combo.lt
- Aprašymas
- Atsiliepimai (0)
Aprašymas
Specifications
Nominal Diameter: 250 mm (10 in)
Minimum Impedance: 6.5 Ω
Continuous Power Handling: 700 W
Frequency Range: 65 Hz – 6000 Hz
Winding Material: Aluminium
Winding Depth: 12 mm (0.47 in)
Flux Density: 1.25 T
Nominal Impedance: 8 Ω
Nominal Power Handling: 350 W
Sensitivity: 100 dB
Voice Coil Diameter: 64 mm (2.5 in)
Former Material: Glass Fibre
Magnetic Gap Depth: 8 mm (0.31 in)
Woofer Cone Treatment: Waterproof Impregnated Cone
Parameters
Fs: 65 Hz
Qes: 0.27
Qts: 0.26
Sd: 346 cm² (53.63 in²)
Xmax: 4 mm
Mms: 32 g
Le: 0.39 mH
Re: 5.5 Ω
Qms: 5.6
Vas: 28 dm³ (0.99 ft³)
η₀: 3.2%
Xvar: 5.5 mm
Bl: 16.9 Tm
EBP: 241 Hz
Design
Surround Shape: Double Roll
Magnet Material: Neodymium Inside Slug
Pole Design: T-Pole
Recommended Enclosure: 26 dm³ (0.92 ft³)
Cone Shape: Radial
Spider: Single
Woofer Cone Treatment: Waterproof Impregnated Cone
Recommended Tuning: 65 Hz
Mounting and Shipping Info
Overall Diameter: 261 mm (10.28 in)
Baffle Cutout Diameter: 230 mm (9.06 in)
Flange and Gasket Thickness: 14 mm (0.55 in)
Net Weight: 3.25 kg (7.17 lb)
Shipping Weight: 3.85 kg (8.49 lb)
Bolt Circle Diameter: 245 mm (9.65 in)
Depth: 125 mm (4.92 in)
Air Volume Occupied by Driver: 1.5 dm³ (0.05 ft³)
Shipping Units: 1 pcs
Shipping Box: 295x314x175 mm (11.61×12.36×6.89 in)
Service Kit
Recone Kit: RCK10MBX648
Cone
Gasket
Centering Shims
