1″ B&C ME10V3
The ME10v3 replaces the ME10v2. The revised design adds two additional mounting holes to expand driver compatibility. The ME10v3 should be backwards compatible with most previous applications for the ME10, but we recommend that all users check the product revised drawings, to be certain.
Key Features
- 1″ throat entry
- 90° x 60° nominal coverage
- Hyperbolic Cosine Flare
- Excellent loading down to 1.5 kHz
Teirautis telefonu
+37069873838
darius@combo.lt
- Aprašymas
- Atsiliepimai (0)
Aprašymas
Specifications
Throat Diameter: 25 mm (1 in)
Nominal Coverage Horizontal: 90 °
Nominal Coverage Vertical: 60 °
Cutoff Frequency: 1.5 kHz
Material: ABS
Design: Hyperbolic Cosine Flare
Dimensions: 130.5×130.5×90 mm (5.1×5.1×3.5 in)
Mounting and Shipping Info
Driver Mounting: 4x 5.5 mm (0.22 in) holes 90° on 76 mm (3 in) diameter — 2x 6.3 mm (0.25 in) holes 180° on 57.2 mm (2.26 in) diameter — 2x 6.3 mm (0.25 in) holes 180° on 53 mm (2.09 in) diameter
Baffle Cutout Dimension: 104 mm (4.1 in)
Air Volume Occupied by Driver: 0.15 dm³ (0.01 ft³)
Net Weight: 0.17 kg (0.37 lb)
Shipping Units: 1 pcs
Shipping Weight: 0.23 kg (0.5 lb)
Shipping Box: 165x165x100 mm (6.50×6.50×3.94 in)
