1.4″ B&C DE82TN 8Ω|16Ω

0 out of 5
( Atsiliepimų dar nėra. )

Key Features

  • 220 W continuous program power capacity
  • 1.4′ horn throat diameter
  • 75 mm (3 in) aluminium voice coil
  • Titanium diaphragm
  • 500 – 18000 Hz response
  • 106.5 dB sensitivity
  • Shorting copper cap for extended HF response

Teirautis telefonu

+37069873838

darius@combo.lt

Facebook Twitter Linkedin
Availability: Išankstinis užsakymas Categories , , , Tags , , ,

Aprašymas

Specifications

Throat Diameter: 36 mm (1.4 in)
Nominal Impedance: 8 Ω
Minimum Impedance: 8.5 Ω
Nominal Power Handling: 110 W
Continuous Power Handling: 220 W
Sensitivity: 106.5 dB
Frequency Range: 500 kHz – 18 kHz
Recommended Crossover: 1 kHz
Voice Coil Diameter: 75 mm (3 in)
Winding Material: Aluminium
Inductance: 0.14 mH
Flux Density: 1.8 T
Diaphragm Material: Titanium
Min Frequency Range: 500 Hz
Max Frequency Range: 18 Hz

Mounting and Shipping Info

Mounting: Four M6 holes 90° on 102 mm (4 in) diameter
Overall Diameter: 170 mm (6.7 in)
Depth: 64 mm (2.5 in)
Net Weight: 4.44 kg (9.79 lb)
Shipping Units: 1 pcs
Shipping Weight: 4.56 kg (10.05 lb)
Shipping Box: 190x190x80 mm (7.48×7.48×3.15 in)
