1.4″ B&C DE620TN
Key Features
- 160 W continuous program power capacity
- 1.4′ horn throat diameter
- 65 mm (2.5 in) aluminium voice coil
- Titanium diaphragm
- 1000 – 18000 Hz response
- 107 dB sensitivity
- Neodymium magnet assembly with shorting copper cap
Teirautis telefonu
+37069873838
darius@combo.lt
- Aprašymas
- Atsiliepimai (0)
Aprašymas
Specifications
Throat Diameter: 36 mm (1.4 in)
Nominal Impedance: 8 Ω
Minimum Impedance: 7.9 Ω
Nominal Power Handling: 80 W
Continuous Power Handling: 160 W
Sensitivity: 107 dB
Frequency Range: 1 kHz – 18 kHz
Recommended Crossover: 1.2 kHz
Voice Coil Diameter: 65 mm (2.5 in)
Winding Material: Aluminium
Inductance: 0.15 mH
Flux Density: 1.8 T
Diaphragm Material: Titanium
Min Frequency Range: 1 Hz
Max Frequency Range: 18 Hz
Mounting and Shipping Info
Mounting: Four M6 holes 90° on 102 mm (4 in) diameter
Overall Diameter: 115 mm (4.5 in)
Depth: 52 mm (2 in)
Net Weight: 1.75 kg (3.85 lb)
Shipping Units: 1 pcs
Shipping Weight: 1.79 kg (3.94 lb)
Shipping Box: 120x120x65 mm (4.72×4.72×2.56 in)
Service Kit
hf Replacement Diaphragm: MMD620TN8M
