1.4″ B&C DE254TN

Specifications

Throat Diameter: 36 mm (1.4 in)
Nominal Impedance: 8 Ω
Minimum Impedance: 7.8 Ω
Nominal Power Handling: 60 W
Continuous Power Handling: 120 W
Sensitivity: 106.5 dB
Frequency Range: 1 kHz – 19 kHz
Recommended Crossover: 1.5 kHz
Voice Coil Diameter: 44 mm (1.7 in)
Winding Material: Aluminium
Inductance: 0.11 mH
Flux Density: 1.85 T
Diaphragm Material: Titanium
Min Frequency Range: 1 Hz
Max Frequency Range: 19 Hz

Mounting and Shipping Info

Mounting: Four M6 holes 90° on 102 mm (4 in) diameter
Overall Diameter: 120 mm (4.7 in)
Depth: 85 mm (3.3 in)
Net Weight: 2.4 kg (5.3 lb)
Shipping Units: 1 pcs
Shipping Weight: 2.44 kg (5.39 lb)
Shipping Box: 135x135x93 mm (5.31×5.31×3.66 in)

Service Kit

hf Replacement Diaphragm: MMD5028M
Available in Fast-On Version

Specification PDF
