1″ B&C DE14TN 8Ω|16Ω

Specifications

Throat Diameter: 25 mm (1 in)
Minimum Impedance: 7.4 Ω
Continuous Power Handling: 60 W
Frequency Range: 1.5 kHz – 18 kHz
Voice Coil Diameter: 36 mm (1.4 in)
Inductance: 0.14 mH
Diaphragm Material: Titanium
Max Frequency Range: 18 Hz
Nominal Impedance: 8 Ω
Nominal Power Handling: 30 W
Sensitivity: 105 dB
Recommended Crossover: 2.2 kHz
Winding Material: Aluminium
Flux Density: 1.45 T
Min Frequency Range: 1.5 Hz

Mounting and Shipping Info

Mounting: Two M5 holes 180° on 76 mm (3 in) diameter
Mounting: Three M6 holes 120° on 57 mm (2.2 in) diameter
Overall Diameter: 90 mm (3.5 in)
Net Weight: 1 kg (2.2 lb)
Shipping Weight: 1.03 kg (2.27 lb)
Depth: 49 mm (2 in)
Shipping Units: 1 pcs
Shipping Box: 105x105x65 mm (4.13×4.13×2.56 in)

Specification PDF
