1.4″ B&C WG148-464-ME148
Key Features
- Line Array optimized Waveguide + Flare with DCX464-8 driver
- Time coherent coaxial ring radiator design (Patents EP3644623B1, US11343608B2)
- 110.5 dB sensitivity
- 220 W continuous program power capacity
- 100° max horizontal coverage
- Vertical coverage depends on configuration
- Very good loading and directivity control down to 700 Hz
- Neodymium magnet assembly
Teirautis telefonu
+37069873838
darius@combo.lt
- Aprašymas
- Atsiliepimai (0)
Aprašymas
Specifications Horn Unit
Nominal Impedance: 8 Ω
Horizontal Coverage: 100 ° Max
Active Radiating Factor: 93.3 %
Specifications MF Unit
Minimum Impedance: 6.3 Ω
Nominal Power Handling: 110 W
Continuous Power Handling: 220 W
Sensitivity: 110.5 dB
Frequency Range: 0.3 kHz – 5.5 kHz
Min Frequency Range: 0.3 Hz
Max Frequency Range: 5.5 Hz
Recommended Crossover: 0.7 kHz
Voice Coil Diameter: 100 mm (4 in)
Winding Material: Aluminium
Inductance: 0.21 mH
Flux Density: 1.9 T
Diaphragm Material: HT Polymer Ring
Specifications HF Unit
Minimum Impedance: 9.1 Ω
Nominal Power Handling: 80 W
Continuous Power Handling: 160 W
Sensitivity: 109 dB
Frequency Range: 3.5 kHz – 18 kHz
Min Frequency Range: 3.5 Hz
Max Frequency Range: 18 Hz
Recommended Crossover: 4 kHz
Voice Coil Diameter: 65 mm (2.5 in)
Winding Material: Aluminium
Inductance: 0.1 mH
Flux Density: 2.14 T
Diaphragm Material: HT Polymer Ring
Mounting and Shipping Info
Net Weight: 5.06 kg (11.16 lb)
Dimensions: 260x260x327.6 mm (10.2×10.2×12.9 in)
Driver Diameter: 152 mm (5.98 in)
Service Kit
HF Replacement Diaphragm: MMDDCX464HF8
MF Replacement Diaphragm: MMDDCX464MF8
