1.4″ B&C ME464-354 8Ω|16Ω
Key Features
- Constant Directivity horn with DCX354-16 driver
- Time coherent coaxial ring radiator design
- 80×60° nominal coverage
- 111.2 dB sensitivity
- 180 W continuous program power capacity
- Neodymium magnet assembly
- revised 20/10/20
Teirautis telefonu
+37069873838
darius@combo.lt
- Aprašymas
- Atsiliepimai (0)
Aprašymas
Specifications Horn Unit
Nominal Impedance: 16 Ω
Nominal Coverage Vertical: 60 °
Nominal Coverage Horizontal: 80 °
Cutoff Frequency: 0.3 kHz
Specifications MF Unit
Minimum Impedance: 12 Ω
Nominal Power Handling: 90 W
Continuous Power Handling: 180 W
Sensitivity: 111.2 dB
Frequency Range: 0.4 kHz – 6 kHz
Min Frequency Range: 0.4 Hz
Max Frequency Range: 6 Hz
Recommended Crossover: 0.4 kHz
Voice Coil Diameter: 76 mm (3 in)
Winding Material: Aluminium
Inductance: 0.26 mH
Flux Density: 1.93 T
Diaphragm Material: HT Polymer Ring
Specifications HF Unit
Minimum Impedance: 10.5 Ω
Nominal Power Handling: 50 W
Continuous Power Handling: 100 W
Sensitivity: 108.5 dB
Frequency Range: 5 kHz – 20 kHz
Min Frequency Range: 5 Hz
Max Frequency Range: 20 Hz
Recommended Crossover: 4.5 kHz
Voice Coil Diameter: 51 mm (2 in)
Winding Material: Aluminium
Inductance: 0.1 mH
Flux Density: 1.96 T
Diaphragm Material: HT Polymer Ring
Mounting and Shipping Info
Exit Size: NaN in
Net Weight: 7.3 kg (16.09 lb)
Driver Diameter: 130 mm (5.12 in)
Baffle Cutout Diameter: 538 mm (21.18 in)
Shipping Box: NaN in
Dimensions: 575x505x535 mm (22.64×19.88×21.06 in)
