B&C 15PLB76
€0.00
- 800 W continuous program power capacity
- 76 mm (3 in) copper voice coil
- 40 – 2000 Hz response
- 100 dB sensitivity
- Aprašymas
- Atsiliepimai (0)
Aprašymas
|
SPECIFICATIONS |
|
|
Nominal Basket Diameter |
15” / 320mm |
|
Impedance |
8 ohms |
|
RMS Power Rating |
400 Watts |
| Program Power | 800 Watts |
|
Frequency Response |
40Hz – 2.0kHz |
|
Sensitivity (1W/1m) |
100dB |
|
Voice Coil Diameter |
3″ / 76mm |
| Winding Material | Copper |
| Former Material | Glass Fibre |
| Winding Depth | .65″ / 16mm |
| Magnetic Gap Depth | .4″ / 10.5mm |
| Flux Density | 1.15T |
|
MOUNTING INFORMATION |
|
| Overall Diameter | 15.5″ / 394mm |
| Bolt Circle Diameter | 14.6″ / 374mm |
| Baffle Cutout Diameter | 13.9” / 355mm |
| Depth | 6.7″ / 170mm |
| Flange & Gasket Thickness | .625″ / 16mm |
| No. Of Mounting Holes | 8 |
| Net Weight | 19.1 lbs./ 8.7kg. |
|
THIELE-SMALL PARAMETERS |
|
|
Resonant Frequency (fs) |
42 Hz |
| Impedance (Re) | 5.0 ohms |
| Electrical Factor(Qes) | .26 |
| Mechanical Q (Qms) | 5.9 |
| Total Q (Qts) | .25 |
| Compliance Equiv. Vol. (Vas) | 154 Liters/5.4cu. ft. |
| Voice Coil Overhang (Xmax) | 5.0mm |
| Reference Efficiency | 4.5% |
| BL Factor | 22.1 T-M |
| Coil Inductance (Le) | 1.3mH |
