B&C 12TBX100
€0.00
- 2000 W continuous program power capacity
- 100 mm (4 in) copper voice coil
- 45 – 1000 Hz response
- 95 dB sensitivity
- Aluminium demodulating ring allows a very low distortion figure
- Double silicone spider with optimized compliance
- Ventilated voice coil gap for reduced power compression
- Aprašymas
- Atsiliepimai (0)
Aprašymas
|
SPECIFICATIONS |
|
|
Nominal Basket Diameter |
12” / 320mm |
|
Impedance |
8 ohms |
|
RMS Power Rating |
1,000 Watts |
| Program Power | 2,000 Watts |
|
Frequency Response |
45Hz – 1.5kHz |
|
Sensitivity (1W/1m) |
95dB |
|
Voice Coil Diameter |
4″ / 100mm |
| Winding Material | Copper |
| Former Material | Fiber Glass |
| Winding Depth | 1.0″ / 25mm |
| Magnetic Gap Depth | .5″ / 12mm |
| Flux Density | 1.1T |
|
MOUNTING INFORMATION |
|
| Overall Diameter | 12.56″ / 319mm |
| Bolt Circle Diameter | 11.77″ / 299mm |
| Baffle Cutout Diameter | 11.1″ / 282mm |
| Depth | 5.5” / 140mm |
| Flange & Gasket Thickness | .625″ / 16mm |
| No. Of Mounting Holes | 8 |
| Net Weight | 22.4 lbs./ 10.2 kg. |
|
THIELE-SMALL PARAMETERS |
|
|
Resonant Frequency (fs) |
42 Hz |
| Impedance (Re) | 5.1 ohms |
| Electrical Factor(Qes) | .27 |
| Mechanical Q (Qms) | 6.9 |
| Total Q (Qts) | .26 |
| Compliance Equiv. Vol. (Vas) | 37.5 Liters/1.3cu. ft. |
| Voice Coil Overhang (Xmax) | 9.0mm |
| Reference Efficiency | 1.15% |
| BL Factor | 25.5 T-M |
| Surface Area of Cone (Sd)m2 | 0.0823m2 |
| Coil Inductance (Le) | 1.6mH |
| SPL VS. FREQUENCY
|
|
