Yamaha CBR Series

0 out of 5
( Atsiliepimų dar nėra. )

POWER TO PLAY

The CBR Series is a new lineup of passive loudspeakers developed by adopting the extensive knowledge of speaker designand acoustic technologies that Yamaha has accrued over a long and storied history of making speakers of every kind.Combining a meticulous materials selection process, thorough customization of the audio components, and a fresh, innovativeapproach to speaker design, our engineering team’s primary focus was to deliver high-power, high-definition sound in a highlyportable and versatile design that is equally at home in front-of-house, floor monitoring, or rigged configurations.- Custom Designed Transducers and Wide-Dispersion Constant Directivity Horn for Powerful High-Definition Sound- HF Protection Function and Highly Responsive LF Unit for Reliable Performance at Any Output Level- Rugged, Highly Portable Enclosure Design- Simple Connectivity- Versatility for a Variety of Applications

Teirautis telefonu

+37069873838

darius@combo.lt

Facebook Twitter Linkedin
Availability: Išankstinis užsakymas Categories , , Tags ,

Aprašymas

General specifications CBR15 CBR12 CBR10
Speaker type 2-way Speaker, Bass-reflex Type
Frequency range (-10dB) 46 Hz – 20 kHz 48 Hz – 20 kHz 50 Hz – 20 kHz
Nominal coverage H: 90°, V: 60°
LF 15″ Cone, 2.5″ Voice Coil (Ferrite Magnet) 12″ Cone, 2″ Voice Coil (Ferrite Magnet) 10″ Cone, 2″ Voice Coil (Ferrite Magnet)
HF 1.4″ Voice Coil, Compression Driver (Ferrite Magnet) 1.4″ Voice Coil, Compression Driver (Ferrite Magnet) 1″ Voice Coil, Compression Driver (Ferrite Magnet)
Crossover 2.0 kHz 2.1 kHz 2.8 kHz
Power rating – NOISE 250W 175W 175W
Power rating – PGM 500W 350W 350W
Power rating – PEAK 1000W 700W 700W
Nominal Impedance 8Ω
SPL (Sensitivity 1W/1m) 96 dB SPL 96 dB SPL 94 dB SPL
SPL (Peak Calculated) 126 dB SPL 125 dB SPL 123 dB SPL
I/O connectors 1/4″ Phone x1, speakON NL4MP x1 1/4″ Phone x1, speakON NL4MP x1 1/4″ Phone x1, speakON NL4MP x1
Cabinet material Plastic
Finish Black
Handle Side x2 Side x2 Top x1
Flying and mounting hardware Bottom x2, Rear x1 (Fit for M8 × 15 mm Eyebolts) Bottom x2, Rear x1 (Fit for M8 × 15 mm Eyebolts) Bottom x2, Rear x1 (Fit for M8 × 15 mm Eyebolts)
Pole socket Ø35 mm, Bottom x1 Ø35 mm, Bottom x1 Ø35 mm, Bottom x1
Dimensions (W × H × D) 455 mm × 700 mm × 378 mm
(17.9″ × 27.6″ × 14.9″)		 376 mm × 601 mm × 348 mm
(14.8″ × 23.7″ × 13.7″)		 308 mm × 493 mm × 289 mm
(12.1″ × 19.4″ × 11.4″)
Net weight 17.7 kg (39.0 lbs) 13.9 kg (30.6 lbs) 10.4 kg (22.9 lbs)
Accessories Optional Speaker Bracket: BBS251, BCS251, BWS251-300, BWS251-400 Same as CBR15 Same as CBR15
