Stiprintuvas Powersoft T902 A
The T Series is a very flexible and cost-effective amplifier platform with loudspeaker processor.
All models deliver the same high peak voltage allowing high SPL with single 8/16 ohm cabinets on all models. The high voltage is also good for sharing power between the channels for applications such as bi-amped loudspeakers or subwoofers with passive tops.
MyPowersoft services are available for this product.
Teirautis telefonu
+37069873838
darius@combo.lt
- Aprašymas
- Atsiliepimai (0)
Aprašymas
- The loudspeaker processing sets a new benchmark for cost-effective amplification for small and medium-sized systems and stage monitors. The T Series can be controlled and configured in different ways.
- Full control with a PC running Armonía.
- Control from the front panel display for features like preset recall (also per output), gain, delay, mute. This makes it very easy to use for small systems in a rental company. The display also shows the available headroom with easy to read numbers in dB as well as other status monitoring parameters.
- Web app. Use any device with a browser (e.g. a tablet) and access the amplifier via an external WiFi access point for easy control.
- Group controllable advanced EQ with raised cosine filters
- Large preset library
- Preset compatibility with X Series
- Long FIR filters (42.6 ms)
- Control and monitoring through ArmoníaPlus
| GENERAL | ||
|---|---|---|
| Output power per channel | 4000 W @ 2 Ω 3200 W @ 4 Ω 1800 W @ 8 Ω |
|
| Bridge mode | 8000 W @ 4 Ω 6400 W @ 8 Ω |
|
| Max output voltage / current | ||
| Max unclipped output voltage @ 8 Ω | 175 Vpeak | |
| Current | 110 Apeak | |
| AC MAIN POWER | ||
| Power supply | Universal, regulated switch mode with PFC (Power Factor Correction) | |
| Nominal power requirement | 100-240 V ±10%, 50-60 Hz | |
| Operating voltage | 90 V – 264 V | |
| Power consumption / Current draw | ||
| 1/8 of max output power @ 4 Ω | 120 V: 1073 W – 9.6 A | 230 V: 1068 W – 5.3 A |
| THERMAL | ||
| Thermal dissipation | 120 V | 230 V |
| 1/8 of max output power @ 4 Ω | 931 BTU/h | 913 BTU/h |
