- Multiple mounting options
- Auto-Setup
- Power-sharing
- Full remote control via 3rd party controls
Stiprintuvas Powersoft MEZZO 322 A+
Mezzo 322 A+ heralds the same levels of reliability, build quality, and acoustic proprieties of any Powersoft amplifier platform, in half the size. Exceedingly flexible, “A+” versions of Mezzo offer all the remote control and monitoring functions of the “A” versions, further extending networking capabilities with AES67. The small form factor allows it to be mounted anywhere thanks to the included mounting kit. The 320 W versions of Mezzo can also be mounted in air handling spaces, such as ceilings or wall boxes. Two-channel versions of Mezzo also feature 2 line-level outputs, further extending routing options
MyPowersoft services are available for this product.
Teirautis telefonu
+37069873838
darius@combo.lt
- Aprašymas
- Atsiliepimai (0)
Aprašymas
Features
| GENERAL | ||
|---|---|---|
| Output power per channel | 160 W @ 2 Ω 160 W @ 4 Ω 160 W @ 8 Ω |
|
| Maximum power-sharing capacity per channel | 320 W @ 4 Ω 320 W @ 8 Ω |
|
| Max output voltage / current | ||
| Maximum unclipped output voltage | 142 Vpeak | |
| Maximum output current | 15.6 Apeak | |
| AC MAIN POWER | ||
| Power supply | Universal, regulated switch mode with PFC (Power Factor Correction) | |
| Nominal power requirement | 100-240 V ±10%, 50-60 Hz | |
| Operating voltage | 90 V – 264 V | |
| Power consumption / current draw | ||
| Idle | 115 V: 12 W – 0.23 A | 230 V: 13 W – 0.2 A |
| 1/8 of max output power @ 4 Ω | 115 V: 73 W – 0.68 A | 230 V: 77 W – 0.44 A |
| THERMAL | ||
| Thermal dissipation* | 115 V | 230 V |
| Idle | 41 BTU/h | 46 BTU/h |
| 1/8 of max output power @ 4 Ω | 81 BTU/h | 97 BTU/h |
