JB-LIGHTING Sparx 12 Pixel-Washer

0 out of 5
( Atsiliepimų dar nėra. )

The Sparx 12 is equally impressive as an effects unit with single pixel control and TwinZoom for backlighting applications or as an excellent wash light with perfectly homogeneous beams over the entire zoom range of 3,2° – 55°.

The 19 by 40 W of the light 15.5 kg Sparx 12 makes conventional 2 kW spotlights look pale in comparison for color applications. It also guarantees perfectly homogeneous illumination with a level of intensity, brilliance and speed that’s sure to be fun and entertaining.

Teirautis telefonu

+37069873838

darius@combo.lt

Facebook Twitter Linkedin
Availability: Išankstinis užsakymas Categories , , , Tags , , ,

Aprašymas

Optics and light source

  • 19 RGBW high-performance LEDs of 40 W each, up to 10,500 lm Output
  • > 20.000 h life time
  • Flicker-free operation, camera mode: 100, 120 and 600 Hz
  • TwinZoom system: Zoom range 3,2° – 55° (1:17,2)
  • Highly efficient optics for perfect color mixing

Effects

  • Individual LED control – Single pixel control
  • Sparkle channel for dynamic effects
  • Multiple layers with independent patterns can be stacked on top of each other
  • Countless color and pattern combinations
  • Separate CTC channel
  • Optimised color mixing behaviour
  • High-resolution, steplessly variable dimmer 0–100%
  • Color-accurate dimming
  • Electronic strobe with pulse and random effects
  • TwinZoom effects: Multicolor beams and innovative beam shapes
  • Basic color temperature can be selected: 2700 K, 3200 K, 4200 K, 5600 K, 6000 K, 6500 K, 7000 K or 8000 K

Movement

  • 3 phase extra strong stepping motors
  • Precise, very fast and silent movement
  • 540° pan / 330° tilt

Control and programming

  • USITT DMX-512, RDM
  • Ethernet interface with Art-Net, sACN and Kling-Net
  • Wireless DMX / RDM Lumen Radio CRMX TiMo
  • Bluetooth, Wifi
  • LCD display with function keys and battery buffer, electronically rotatable
  • Mini USB for software update
  • Stand-alone mode, master/slave function
  • Built-in DMX analyser

Construction

  • Robust, roadworthy design
  • Individually changeable LEDs
  • Fan control for almost noiseless operation, 29 dB(A)
  • Neutrik 5pin XLR IN/OUT
  • RJ45 IN/OUT network socket
  • Power IN/OUT
  • 5pin IN/OUT socket (prepared for battery operation)

Rigging

  • 2 Omega brackets with Original Camloc® fasteners for quick and convenient installation in any position, with four different fastening options

Electrical & thermal specification

  • Max. power consumption 750 VA
  • Input voltage range 100 V–240 V, 50/60 Hz
  • Total heat dissipation (calculated): 2,560 BTU/hr

Mechanical specification

  • Dimensions: B 404 x D 265 x H 491 mm
  • Weight: 15,5 kg

Scope of delivery

  • Schuko on powerCON TRUE1, flexible rubber cable (2 m long, 3 x 1.5 mm²)
  • 2 Omega brackets

Accessories

  • CASE42 Amptown double flight case
  • CASE43 Amptown 4-compartment flight case
  • ZU0027 Beamshape rotatable
  • BLOB02 Omega bracket standard
