Aprašymas

Specifications

Features

• Node-based programming for flexibility with Salvation
• Send or receive video over IP with NDI® by NewTek
• 3D projection mapping
• Supports Notch (license required)
• Easily set up projector blending with AutoBlend
• AiM media transcoder
• Synergy with Avolites Titan

Video & Audio I/O

• Minimum 2 layers of video simultaneously to every output
• 1 x HDMI dedicated GUI output (up to 3840×2160 @ 60Hz)
• 4 x HDMI production outputs (up to 3840×2160 @ 60Hz)
• Stereo balanced XLR audio output with ground lift
• XLR SMPTE input and loop out
• Video Sync BNC Genlock (optional)

Connectivity & Storage

• 2TB NVMe VROC-accelerated media drive
• MIDI In – 1 x 5-pin DIN
• DMX via ArtNet and sACN
• 2 x Gigabit LAN on etherCON
• 1 x 10 Gigabit LAN on etherCON
• PowerCon True1 in/thru
• Input voltage: 100–250 V, 50/60 Hz (auto-ranging)
• Power consumption: 800 VA (max)

Physical Specifications
