Luxibel B PANEL240CW
€0.00
240x LED Cold White Studio Panel
The B PANEL240CW is the most versatile, powerful and ease of use cold white panel on the market. It’s equipped with barndoors and a removable frost and gel frame. B PANEL240CW comes with manual dimming and DMX. Furthermore this panel has a Hi CRI (96) what makes it ideal for TV, theatre, photography and much more…
- Aprašymas
- Atsiliepimai (0)
Aprašymas
PHYSICAL
Dimensions (WxHxD)
526 x 316 x 125 mm
Packiging dimensions (WxHxD)
560 x 380 x 180 mm
Outer carton dimensions (2 pieces)
580 x 380 x 180 mm
Nett weight
8 kg
Gross weight (1 piece)
9 kg
Gross weight (2 pieces)
18,5 kg
MOUNTING OPTIONS
Hanging
3x hole for M12 bolt
2nd suspension / safety wire
1x eye on the side top of the fixture to pass a safety wire or carabiner
CONTROL
Menu control
Via TFT 4 digit display with 4 buttons
Control
DMX512, manual dimming button
In/Link
XLR 5 pin
DMX mode
1/2/3 channels
OPTICAL
Beam angle
160°
Light output
790 lux @ 2m | 300 lux @ 4m | 150 lux @ 6m
Refresh rate
<1000 Hz
Colours
White, 5000K
CRI
95,8 RA
Strobe
0-20 Hz
ELECTRICAL
Fixture rated power
120W
Input power
100 – 240V ~ 50/60 Hz – Auto switching power supply
LED engine
240x White SMD LED
In/Link
PowerCON TRUE1 – max link current 10A
ENVIRONMENTAL
Max. housing temperature
50°
Cooling
Convectional – no fans
IP rating
IP20
ACCESSORIES
1x Power cord TRUE1
Included
1x Gelframe
Included
1x Soft frost
Included
1x Intensifier
Included
1x Barndoors
Included
